42V 4A electric scooter universal charger for Lithium-ion batteries

Case:	Aluminum	Dimension:	155*90*50 MM
N. W.:	1 KG	Input Volt:	110 – 230Vac
Max Output:	42V 4A	Applied Battery:	Lithium-ion Battery
Color:	Black Or Silver	Output Power:	180W Max
Warranty:	2 Years	Charge EV:	E-scooters, E-bikes
Highlight:	e-scooter charger, electric bike charger 24v

Electric scooter battery charger 36V 42V 4A for lithium ion batteries high efficiency

Brief Description:

Automatic 42V 4A lithium ion battery charger, smart charge LiFePO4 / Li ion / LiMO2 batteries. Input with 110 – 240 Vac and charging with 42 Vdc 4 amps, max 180 watts output power. Smart 4 steps charging: pre charge, CC, CV and automatic shut off and maximumly protecting your expensive lithium batteries. Small size, portable for electric scooters, electric mobility and electric skateboard. We can customize input and output by your battery specifications.

Features:

◆ Advanced high frequency switching mode power supply technology.

◆ DC output isolated from AC input.

◆ Auto worldwide Input 110 / 230Vac(90 ~ 264Vac), 50Hz ~ 60Hz.

◆ Charging parameters are insensitive to the AC input line voltage variations.

◆ Completely automatic battery charging: Pre charging, CC, CV, Absorption, Float or Cut – off.

◆ 2 LEDs: LED1 Red (power on), LED2 Red / green (charging/full)..

◆ Possibility to customize charging curve for request.

◆ Protections: short circuit, over voltage, over temperature, reverse Polarity.

◆ Efficiency > 95%.

◆ Forced ventilation with fans.

◆ 100% full load burn-in test.

◆ Aluminum casing, light weight, portable.

Technical Specs.:

1) Dimensions(LxWxH): 155 x 90 x 50 mm

2) Net weight: 1.0 KG

3) Max charging voltage(CV): 42 volt

4) Floating voltage: customized

5) Max output current (CC): 4 amps

6) Charging method: automatic pre-charge, CC, CV, floating / trickle or shut off

7) AC input voltage: 110 – 240Vac universal

8) AC input freq.: 50 / 60 Hz

9) AC plug: customized by user’s country

10) Output connector type: customized by applications

11) Enclosure: Aluminum

Place of Origin:	CHINA
Brand Name:	OEM
Certification:	CE, ROHS
Model Number:	VL3604L

Packaging Details:12 pcs / carton
